2 - 24 mm Thickness Panel Making Machines with 4 kw Hydraulic power 1.1kw Vibration power

2 - 24 mm Thickness Panel Making Machines with 4 kw Hydraulic power 1.1kw Vibration power

 New Cement Light Wallboard Forming Machine, MGO Board Production Line,mgo panel making machines

MGO board machine

1. Specification:

Thickness: 2-24mm

Width: 600mm-1300mm

Length: 2400mm-3000mm

Capacity: 200 -----2500 square metres per day 8 hours.

Configuration: Customization

2. Usage of product

The magnesium oxide board (glass magnesium board or MGO board)is made of filling materials, such as sawdust and all kinds of crushed plant straw (you can select any one kind ) and several chemical raw materials which are token as modified material after special technology. The board has such features: Quickly hard, high strength, large format, fireproofing, dampproof and good waterproof performance. It can be nailed, planed and sticked, so it can be used widely at indoor decoration, such as wall skirting and ceiling of market, hotel, club, station, office building and living room. And it can get large usage at topgrade furniture, door and partition. This product is made of waste materials, and it is ideal product which can replace all kinds of wood broad with reasonable price and good quality. New cement Light wallboard Forming machine's application:
GRC light wallboard, air-ejected light wallboard, light gypsum wallboard, air-ejected wallboard with steel wire.

Machine weight  About 5T
Machine dimension  3.05*2.25*1.2m
Voltage  380V
Hydraulic power  4 kw
Vibration power  1.1kw
Heating system power  13 kw
Application  GRC panels, gypsum wallboard, magnesium oxide wall panels of various materials
Length of product  Adjustable within 3 meters
Thickness of product  60/90/100/120/150/180/200 mm
Annual output  50, 000squ. M
Material  Mgo or gypsum or cement, fly ash or lime, fiber and other admixture


Advantages of our machine:
1. Automatically control the temperature (electricity, water, steam can heat it), hydraulic pressure for moulds, configured secondary net, accurate positioning
2. Whole machine vibration, hydraulic pressure whole damper, mother slot and son slot forming at one time, with high rate of mechanization.
3. This machine can produce pre-stress board for outside use and inside use (foaming board, composite board and core board)
4. Plastic core, NO need to wash it.
5...Multi-function: Cement light panel, GRC partition wall board, etc
